Reverse Engineer
Any Glass Panel
in Minutes
Built by Max TA Group LLC for glaziers, contractors, and manufacturers. Input field measurements, validate against industry standards, generate technical drawings, and export DXF files ready for SolidWorks, AutoCAD, or CNC fabrication.
Everything You Need to Reverse Engineer Glass
From field measurements to manufacturing-ready files in one workflow. No CAD experience required.
Fraction Input
Enter dimensions as fractions (32 3/4") or decimals. Automatic conversion and validation.
Live Blueprint Canvas
Real-time technical drawing with dimension lines, angles, and grid overlay.
Hole Pattern Builder
Place holes manually or generate edge patterns. Supports hinge pairs and custom layouts.
DXF Export
Export directly to DXF for SolidWorks, AutoCAD, or CNC machines. Layered output.
Manufacturing Drawings
Generate print-ready drawings with specs table, hole schedule, and title block.
Shape Support
Rectangle, trapezoid, and custom shapes with angle inputs for non-standard panels.
Full Specifications
Glass type, thickness, edge finish, tint — all captured for manufacturing.
Instant Calculations
Auto-calculate area, weight, and square footage as you design.
Three Steps to Manufacturing-Ready
Measure & Input
Take field measurements with a tape measure. Enter dimensions using fractions or decimals — the app handles conversion automatically.
Configure & Preview
Select glass type, thickness, edge finish. Add hole patterns using the visual builder. Watch the blueprint update in real-time.
Export & Manufacture
Download DXF for CAD/CNC or a manufacturing drawing with full specs. Send directly to your glass fabricator.
